14'' Wide Temp TFT Capacitive Touch Screen Module

Experience precision touch control with our 14'' Wide Temp TFT Capacitive Touch Screen Module. Multi-touch (10-point) responsiveness meets industrial durability: 6H hardness, 50cm drop resistance, and -20°C to 70°C operating range. Features 310.3×175.0mm view area with 500gf/cm FPC strength. 14'' wide temp TFT capacitive touch screen module is ideal for industrial applications demanding reliability.

Send Inquiry

Product Description

Supporting small-batch trial orders and custom firmware/interface designs, Tianfu, as a touch screen module supplier, ensures seamless integration into smart controls/portable instruments, backed by a 12-month warranty.

Product Features

1.10-Point Multi-Touch Precision

Advanced projected capacitive technology supports 10 simultaneous touch points for seamless gesture control.

(Source: Page 3 - Product Overview)

2.Industrial-Grade Durability

6H hardness-rated glass survives 50cm steel ball impacts and operates in extreme conditions (-10°C to 60°C).

(Sources: Page 4 - Hardness/Ball Drop Test; Page 3 - Operating Conditions)

3.High-Precision Viewing Area

Optimized 310.3×175.0mm viewable area with ±0.20mm dimensional tolerance for critical applications.

(Source: Page 4 - Visual Area Specifications)

4.Reliability-Certified Design

Validated through 72hr 90% RH humidity tests and 10-cycle thermal shock (-20°C↔70°C) compliance.

Product Specification

Overall Dimensions (L×W×T)	338.56mm × 215.76mm × 2.90mm
TP Sensor Dimensions (L×W×T)	336.56mm × 119.63mm × 0.70mm
Viewable Area (L×W)	310.30mm × 175.00mm
Mechanical Characteristics
Ball Drop Test	64g steel ball from 50cm height (3 impacts)
Hardness	≥6H (JIS K-5400)
Warpage	≤Length × 0.1%
FPC Peeling Strength	≥500gf/cm (ASTM D903/D3807)
Environmental Specifications
Operation Condition	-10℃~+60℃/45%~85% RH
Storage Condition	-20℃~+70℃/45%~85% RH

Product Details

14'' Wide Temp TFT Capacitive Touch Screen Module

Product Application

Tianfu Leading Time

Standard Products		Customized Products
Order Quantity	Delivery Time	Customization Type	Delivery Time
1-30 PCS	Immediately	B/L & FPC & TP	within 5 weeks
31-100 PCS	1 week	B/L & FPC & TP	within 5 weeks
101-500 PCS	within 2 weeks	B/L & FPC & TP	within 5 weeks
501-1000 PCS	within 3 weeks	B/L & FPC & TP	within 5 weeks
1001-5000 PCS	within 3 weeks	BL & FPC & TP	within 6 weeks
5000+ PCS	within 4 weeks	BL & FPC & TP	within 6 weeks
