4.3' High Resolution TFT Capacitive Touch Screen Module

Introducing the 4.3' High Resolution TFT Capacitive Touch Screen Module: Precision-engineered with 104×96mm footprint and ultra-slim 1.3mm profile featuring 0.2mm explosion-proof film. Boasts a responsive 66.2×55mm active area, operates flawlessly from -10°C to +60°C, and meets rigorous ROHS standards. 4.3' high resolution TFT capacitive touch screen module is ideal for industrial applications demanding reliability.

Send Inquiry

Product Description

Supporting small-batch trial orders and custom firmware/interface designs, China TFT LCD display module factory, Tianfu ensures seamless integration into smart controls/portable instruments, backed by a 12-month warranty.

Product Features

1.Military-Grade Resilience

0.2mm explosion-proof film + 1.1mm sensor construction withstands extreme impacts and harsh environments.

2.Industrial Temperature Endurance

Operates flawlessly from -10°C to +60°C with 90% humidity tolerance - ideal for demanding applications.

3.Precision Manufacturing

±0.1mm critical dimension tolerance ensures perfect fit and consistent performance in assembly.

4.Eco-Certified Reliability

ROHS-compliant construction meets global environmental standards while maintaining operational integrity.

Product Specification

Module Type	300LCS Touch Panel
Mechanical Dimensions	104.00±0.1 × 96.00±0.2 × 1.3±0.1 mm (L×W×T)
Active Area	66.20±0.1 × 55.00±0.2 mm (Cover 00)
Thickness Composition	Explosion-proof film: 0.20mm + Sensor: 1.10mm
Operating Environment	-10℃ to +60℃, ≤90% RH
Storage Environment	-20℃ to +70℃, ≤90% RH
Electrical Interface	VDD, QCD, SDI, SSO
Compliance	ROHS Standard
General Tolerance	±0.2mm (unless otherwise specified)
Surface Treatment	Black silkscreen + Dual black lines

Product Details

4.3' High Resolution TFT Capacitive Touch Screen Module

Product Application

Tianfu Leading Time

Standard Products		Customized Products
Order Quantity	Delivery Time	Customization Type	Delivery Time
1-30 PCS	Immediately	B/L & FPC & TP	within 5 weeks
31-100 PCS	1 week	B/L & FPC & TP	within 5 weeks
101-500 PCS	within 2 weeks	B/L & FPC & TP	within 5 weeks
501-1000 PCS	within 3 weeks	B/L & FPC & TP	within 5 weeks
1001-5000 PCS	within 3 weeks	BL & FPC & TP	within 6 weeks
5000+ PCS	within 4 weeks	BL & FPC & TP	within 6 weeks
